YX-OS47 XC7Z100 Dual AD9361 RF Transceiver Module – FMCOMMS5-Style Synchronization Architecture Reference Design [SEO-Optimized] [Google-Compliant]

Sale price: $648.00
Regular price: ~~$811.00~~
Regular price: $648.00
Unit price: per

Vendor: YanTechLab

Only 9 items in stock! Out of stock!

Product variants

Quantity

Guaranteed safe checkout

Description

High‑performance SDR platform based on Xilinx Zynq XC7Z100‑2FFG900 and two AD9361 transceivers. 4 transmit and 4 receive channels (4T4R). Frequency range 70 MHz – 6 GHz, instantaneous bandwidth 56 MHz. Supports channel synchronization for MIMO, phased arrays, and 5G prototyping.

Key features

RF: 2×AD9361 · 4T4R · 70 MHz–6 GHz · 56 MHz BW
Processor: Zynq XC7Z100 · PS DDR3 1 GB · PL DDR3 1 GB · Flash 64 MB
Interfaces: 1 Gb Ethernet (PS) · USB 2.0, UART+JTAG (Type‑C) · SD card · 24 LVDS pairs
Sync: ADF5355 + buffer · GPS module
Enclosure: 80×120×26 mm, CNC metal · 12 V DC

Applications: MIMO, phased arrays, 5G prototyping, spectrum monitoring, multi‑channel data acquisition.

Technical Specifications

RF chip	2× AD9361
Channels	4T4R (4 transmit / 4 receive)
Frequency range	70 MHz – 6 GHz
Instantaneous bandwidth	56 MHz
FPGA	Xilinx Zynq XC7Z100‑2FFG900
DDR3 (PS + PL)	1 GB + 1 GB
Flash	64 MB
Ethernet	1 Gb (PS)
USB / UART / JTAG	USB 2.0, UART+JTAG (Type‑C)
SD card	Yes
LVDS pairs	24
Synchronization	ADF5355 + buffer · GPS module
Enclosure (W×H×D)	80×120×26 mm · CNC metal
Power supply	12 V DC

Applications

MIMO and phased array systems
5G prototyping and research
Spectrum monitoring and analysis
Multi‑channel data acquisition
