Making PlutoSDR Fully Standalone: Auto-Run Custom Scripts on Boot

Configure your PlutoSDR to execute custom scripts or programs automatically on boot — no firmware recompilation required. A one‑time setup for truly headless, standalone operation.

The Problem: Manual Execution After Every Boot

Using the Linaro toolchain, you can cross‑compile programs for the PlutoSDR's ARM core from an Ubuntu host. However, each run still requires:

1. Cross‑compiling on the host
2. Transferring the binary via scp to the PlutoSDR
3. SSH into the PlutoSDR's Linux system
4. Manually executing the program

This is only a semi‑standalone workflow — not very elegant for embedded applications.

The Solution: init.d Autorun Hook

According to official firmware issue #74, starting from firmware version v0.36, PlutoSDR includes a built‑in autorun script capability. The file /etc/init.d/S98autorun contains:

#!/bin/sh
#
# Script to check for and run user-supplied /mnt/jffs2/autorun.sh
#

case "$1" in
  start)
    if test -f /mnt/jffs2/autorun.sh; then
        source /mnt/jffs2/autorun.sh
    fi
    ;;
  stop)
    ;;
  restart|reload)
    ;;
  *)
    echo "Usage: $0 {start|stop|restart}"
    exit 1
esac

exit $?

On every boot, this script checks for the existence of /mnt/jffs2/autorun.sh. If present, it executes it. In other words, anything you place in /mnt/jffs2/autorun.sh will run automatically each time the PlutoSDR powers on.

Quick Test: Creating an Autorun Script

Let's verify the mechanism. First, check the current contents of /root (initially empty):

$ pwd
/root
$ ls

Now create the autorun script:

vi /mnt/jffs2/autorun.sh

Add the following content (creates two empty files in /root):

touch /root/foobar
touch /root/123

Save and exit (:wq in vi).

Power‑cycle the PlutoSDR (unplug and reconnect power). After boot, SSH back in and verify:

$ pwd
/root
$ ls
123     foobar

The autorun script executed successfully on boot!

Persistent Storage for Your Programs

One remaining challenge: the PlutoSDR's Linux system reverts most file changes after reboot. Files created in /root or other directories disappear. How can you store your compiled binary persistently?

Workflow for a fully standalone application:

1. Cross‑compile your program on the host machine using the Linaro toolchain
2. scp the binary to /mnt/jffs2/ on the PlutoSDR
3. Create /mnt/jffs2/autorun.sh that executes your binary (with full path)
4. Make the script executable: chmod +x /mnt/jffs2/autorun.sh
5. Power‑cycle — your program now runs automatically on every boot

Example: Auto‑Running a Custom SDR Application

Suppose you've cross‑compiled a program called my_sdr_app. The setup would look like:

# Copy binary to persistent storage
scp my_sdr_app root@192.168.2.1:/mnt/jffs2/

# Create autorun script
ssh root@192.168.2.1
echo '#!/bin/sh' > /mnt/jffs2/autorun.sh
echo '/mnt/jffs2/my_sdr_app' >> /mnt/jffs2/autorun.sh
chmod +x /mnt/jffs2/autorun.sh

# Reboot to test
reboot

After reboot, my_sdr_app will execute automatically — no host computer needed.

Important Notes

• This method works on PlutoSDR firmware v0.36 and later. Check your version with cat /etc/issue.
• The autorun script runs as root, so you have full system access.
• If your program runs continuously (e.g., a server or data logger), consider adding an ampersand (&) to background it, or use a process manager.
• To stop automatic execution, simply delete or rename /mnt/jffs2/autorun.sh.

Troubleshooting

• Script not executing? Verify the file is at the exact path /mnt/jffs2/autorun.sh and has execute permissions (chmod +x).
• Binary not found? Use absolute paths in your script (e.g., /mnt/jffs2/my_app instead of ./my_app).
• Want to see boot logs? Connect via serial console or check /var/log/messages after boot.
