OmniRange C5 User Manual
Multifunctional Wireless Platform | Flipper Zero Expansion | ESP32 Marauder Ready
🧭 1. Product Overview
The OmniRange C5 is a multifunctional wireless platform designed for both standalone operation and Flipper Zero expansion. It integrates Wi-Fi, Bluetooth, Sub-GHz, and GPS modules, and supports ESP32 Marauder firmware.
- Wireless Research
- RF Data Capture
- Engineering Diagnostics
- Security Testing
⚙️ 2. Flipper Zero Configuration
Firmware Reference: MNTM-011 (02-02-2025)
📌 2.1 Enter Settings
Momentum → Protocol Settings → GPIO Pin Mapping
📌 2.2 Hardware Interface Setup
| Module | Configuration |
| GPS (UBlox / ATGM) |
GPS TX → GPIO 13 GPS RX → GPIO 14 |
| CC1101 Sub-GHz |
Default internal SPI (no change required) External module: Set "Use Module" → External |
| ESP32-C5 Wi-Fi |
TX → GPIO 15 RX → GPIO 16 |
✅ 3. Configuration Result
After setup, Flipper Zero will detect:
- GPS Module
- ESP32-C5 Dual-Band Wi-Fi
- 433 MHz Sub-GHz RF Module
🔄 4. Firmware Update
The OmniRange C5 uses a dual-firmware architecture:
- Standalone Mode
- Flipper Zero Expansion Mode
👉 OmniRange C5 Firmware Update Guide
Includes flashing tools, bootloader steps, and verification process.
🖥️ 5. Standalone Mode
📁 5.1 Features
Runs ESP32 Marauder firmware as a standalone wireless pentesting platform.
- Wi-Fi Analysis
- Bluetooth Scanning
- Packet Monitoring
- Advanced RF Testing
🔗 5.2 Documentation
🎬 5.3 Video Guide
